This article show the guide on how to install DiagBox v8.01 diagnostic software.This method provided by the cartechnology remember simple,big thanks to him selfless work.
Note: If using a Virtual Machine, ensure Virtualization is enabled in the physical laptop BIOS.
Preparation for Installing DiagBox 8.01 on Notebooks and VMWare Workstation
– Starting with any (32 bit) Windows (preferably XP or 7), install .NET 3.51 and Windows drivers or VMWare Tools (if on VMWare Workstation or Player).
Diagbox 7.02 Download Mega
Preparation for Installing DiagBox 8.01 on VirtualBox
– Settings –> System: Motherboard, ensure APIC is OFF, use one processor and enable Virtualization. Allocate enough memory for VM.
– Having installed 32 bit Windows + VirtualBox Guest Additions + .NET 3.51, use the Powershell Command “Get-WMIObject win32_BIOS” or the “DMIdecode” tool to obtain BIOS information (not essential).
– Close VirtualBox and start an administrator’s CMD, navigate to “C:Program FilesOracleVirtualBox” and execute the following command (Replacing “Your VM” with your Virtual Machine’s name, and System Serial with your hardware’s or any code or text such as “CDN29326BH”):
C:Program FilesOracleVirtualBox>VBoxManage setextradata “Your VM” “VBoxInternal/Devices/pcbios/0/Config/DmiSystemSerial” “System Serial”
Installing DiagBox 8.01
1- Install DiagBox 7.01 and restart DiagBox to run update 7.02. Install update 7.xx-7.57 (this will create “C:AWRootdtwrcfgConfig.sys”).
2- Install “VC++ 2008 Redistributable Package”, a copy will be available in “C:teleassistancevisualCvcredist_x86.exe” after installing DiagBox.
3- Restart the computer and use “Kill_DiagBox_Tasks.bat” to stop related processes and rename “C:AWRoot” to “C:AWRoot7”
4- Run DiagBox 8.01 installation (it will uninstall v7.xx first) until it requests Activation. Close it (X) and run the tool “AWRoot_v7_Conf+Ativation_v8.exe” it will copy configuration from “C:AWRoot7..” and inject the necessary files.
5- Run DiagBox again, it should continue the installation successfully.
Diagbox 9.12 free download source, Diagbox 7.83 (working version) source. Also, PSA Diagbox 7.02-7.83 for Lexia 3 diagnostic tool. Newest Diagboxsetupv09.12.exe. Free download Lexia 3 Diagbox 7.02 to 7.82: No pass. Free download Lexia 3 Diagbox 7.82 to 7.83 (8.19): Password: Very Simple! Free download Lexia 3 Diagbox 8.20 to 8.26. PSA Diagbox 8.55 peugeot citroen DS. Install DiagBox 7.01, restart and wait for the update to 7.02. Install updates 7.xx-7.57. This allows you to create the file C: AWRoot dtwr cfg Config.sys. Install the VC 2008 Redistributable Package, if not previously installed. Diagbox download: – Diagbox updates from v8.20 to v8.26. No need password!. DiagBoxfrom v7.82 to v7.83 (8.19) Password: Very Simple! This Diagbox software is provided as is; for personal, educational andexperimental use to upgrade from DiagBox version 7.82 to 7.83 only.I hold no responsibility for any illegal or improper use. Newest BMW E-sys 3.33.0 3.32.1 Free Download; Free Download Op-com Can OBD2 FW 1.99 Opel Diagnostic Tool; Free download Diagbox V9.12 V7.83 for Lexia 3 PP2000 Free download Renault Can Clip V191 V190 V188 V185 V184 V183; New Diagbox 9.23 Installation: Windows 10 or Windows Ksuite 3.40 2.47 Download FREE + 100% Tested.
Done !,
Restart DiagBox 8.01 as Administrator to confirm all is well (don’t be concerned about the reported version and do not start Lexia or PP2000 yet). If you face an issue, run the activation tool again and/or review “Versions” below.
If DiagBox runs fine, ensure you keep a backup copy of the file “C:AWRootbinfiAPPDIAG.SYS” in a safe location.
Installing Updates
1- Download and install “DiagBox_updt_802.ISO” update.
2- Download and install subsequent v8.xx updates or Maitresox updates (from 7.66+).
Tool you need:
DiagBox Full v8.01 ISO:
AWRoot_v7_Conf+Ativation_v8.exe No password
DiagBox updates working with DiagBox V8.01 based on v7.xx profile, Extraction Password: Simple
DiagBox_updt_802_Simple.exe
DiagBox_updt_803-810_Simple.exe
DiagBox_updt_811-814_Simple.exe
DiagBox_updt_815-817_Simple.exe
For those who wish to stay with (ISO 639-1) standard:
DiagBox_updt_803-808_Simple.exe (7.72) Password: Simple #808
And those who wish to continue further:
DiagBox_updt_810_Simple.exe (7.74) No Password
Cache Contents Restorer No password
Kill_DiagBox_Tasks
Versions
DiagBox will run and display the (8.xx or 7.xx) version number listed in “AWRootbinfiversion.ini” file. However, Lexia or PP2000 will fail to operate with “version.ini” set to “08.xx” and “APPDIAG.SYS” will be corrupted and will need to be restored before DiagBox will work again.
So, for DiagBox, Lexia and PP2000 to operate, set the version to “7.xx” or “7.xxx” (07.81 or 07.817 can be set to indicate the true DiagBox 8 version).
[APPLICATION]
version=07.817
It is possible to operate Lexia/PP2000 (after starting DiagBox with 8.xx) by starting DiagBox while having “version.ini” listing the 8.xx only (or first), then changing it to 7.xx or commenting the line “version=08.xx” and saving BEFORE starting LEXIA or PP2000 as shown below.
[APPLICATION]
;version=08.01
version=07.65
Updates
– DiagBox v7 and v8 install and run on all x86 (32bit) Windows including 10 TH1, TH2, RS1 and RS2.
– Entering a System Serial for the Virtual Machine (as described above) resolves the “psaAagent.exe” and the missing tabs issue on VirtualBox.
– If you get “Error 2” after restarting DiagBox, try commenting “version=8.xx” in “version.ini” before restarting DiagBox again.
P.S. DiagBox has been running on Firmware 4.3.4 since 7.66/8.02.
Someone put the full installation process on the net, just edit “version.ini” as described above.
Diagbox 9
Here, free download Lexia 3 software and update DiagBox from v8.20 to v8.26, from v7.82 to v7.83 (8.19). Enjoy! Diagbox download: – Diagbox updates from v8.20 to v8.26
No need password!- DiagBoxfrom v7.82 to v7.83 (8.19)
This Diagbox software is provided as is; for personal, educational andexperimental use to upgrade from DiagBox version 7.82 to 7.83 only.I hold no responsibility for any illegal or improper use. You install this software at your own risk with full responsibility for any damage that may occur to yoursystem as a result of its installation.If you want a safe Diagbox update, you’d better spent some dollars from
Diagbox 9.12 Activation
Diagbox 7.02 Download Free
Once file extraction is complete, restart the computer andrun DiagBox software to finish internet updates installation. Good luck! Tech support from http://www.obd2france.com/ and http://www.autoprofessionals.org/
